Western Blot, Positive WB detected in: 1 lane: Recombinant proteins with LAG3; 2 lane: 293F whole cell lysate transfected with LAG3 , All lanes: LAG3 antibody at 1:2000, Secondary, Goat polyclonal to mouse IgG at 1/50000 dilution, Predicted band size: 76, 88 KDa, Observed band size: 76, 88 KDa, Exposure time：5min
IHC image of CAC12972 diluted at 1:500 and staining in paraffin-embedded human tonsil tissue performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at 37℃ Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-Mouse IgG labeled by HRP and visualized using 0.05% DAB.
IHC image of CAC12972 diluted at 1:500 and staining in paraffin-embedded human appendix tissue performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at 37℃ Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-Mouse IgG labeled by HRP and visualized using 0.05% DAB.
Overlay Peak curve showing A549 cells stained with CAC12972 (red line) at 1:100. The cells were incubated in 10% normal goat serum to block non-specific protein-protein interactions followed by the antibody (1ug/1*10 6 cells) for 1h at 4°C. The secondary antibody used was FITC-conjugated Goat Anti-Mouse IgG(H+L) at 1/100 dilution for 30min at 4°C. Isotype control antibody (green line) was mouse IgG1 (1ug/1*10 6 cells) used under the same conditions. Acquisition of >10,000 events was performed.
LAG3 Monoclonal Antibody - image 5
Western Blot, Positive WB detected in: 1 lane: Recombinant proteins with LAG3; 2 lane: 293F whole cell lysate transfected with LAG3 , All lanes: LAG3 antibody at 1:2000, Secondary, Goat polyclonal to mouse IgG at 1/50000 dilution, Predicted band size: 76, 88 KDa, Observed band size: 76, 88 KDa, Exposure time：5min
IHC image of CAC12972 diluted at 1:500 and staining in paraffin-embedded human tonsil tissue performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at 37℃ Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-Mouse IgG labeled by HRP and visualized using 0.05% DAB.
IHC image of CAC12972 diluted at 1:500 and staining in paraffin-embedded human appendix tissue performed on a Leica BondTM system. After dewaxing and hydration, antigen retrieval was mediated by high pressure in a citrate buffer (pH 6.0). Section was blocked with 10% normal goat serum 30min at 37℃ Then primary antibody (1% BSA) was incubated at 4°C overnight. The primary is detected by a Goat anti-Mouse IgG labeled by HRP and visualized using 0.05% DAB.
Overlay Peak curve showing A549 cells stained with CAC12972 (red line) at 1:100. The cells were incubated in 10% normal goat serum to block non-specific protein-protein interactions followed by the antibody (1ug/1*10 6 cells) for 1h at 4°C. The secondary antibody used was FITC-conjugated Goat Anti-Mouse IgG(H+L) at 1/100 dilution for 30min at 4°C. Isotype control antibody (green line) was mouse IgG1 (1ug/1*10 6 cells) used under the same conditions. Acquisition of >10,000 events was performed.
LAG3 Monoclonal Antibody - image 5

LAG3 Monoclonal Antibody

Vendor: Biomatik

Type: Antibodies

SKU: CAC12972-100UL

$597.19 USD
Shipping calculated at checkout.

Documents

SDS

Available in stock (500)

  • Customs clearance fees may apply
  • Worldwide shipping available.
For research use only — not intended for clinical or diagnostic purposes.

Product Overview

Accession number
P18627
Applications
ELISA, WB, IHC, FC
Buffer
0.03% Proclin 300, 50% glycerol, 0.01M PBS, pH 7.4
Clonality
Monoclonal
Clone number
8B12E10
Concentration
Lot specific. Please inquire or refer to the datasheet included in the product pouch.
Conjugate
Unconjugated. Conjugated antibodies are available (Biotin, FITC and HRP), please inquire.
Description
The LAG3 Monoclonal Antibody is applicable for the following applications: ELISA, WB, IHC, FC.
Expiration
12 months
Format
Liquid
Host
Mouse
Ihc validation
IHC Validated
Immunogen
Recombinant Human Lymphocyte activation gene 3 protein (29-450AA)
Isotype
IgG1
Purification
>95%, Protein G purified
Quality systems
This product is manufactured at ISO 9001 certified facilities.
Research area
Immunology
Restrictions
For Research Use Only. Not for use in diagnostic procedures.
Shipping conditions
Ice packs
Species
Human (Homo sapiens)
Species reactivity
Human (Homo sapiens)
Storage
2°C to 8°C for frequent use, -20°C for 12 months. Avoid repeated freeze/thaw cycles.
Target name
LAG3
Target synonyms
CD223; CD223 antigen; FDC protein; LAG-3; Lag3; LAG3_HUMAN; Lymphocyte activating 3; Lymphocyte activation gene 3; Lymphocyte activation gene 3 protein; Protein FDC
Western Blot, Positive WB detected in: 1 lane: Recombinant proteins with LAG3; 2 lane: 293F whole cell lysate transfected with LAG3 , All lanes: LAG3 antibody at 1:2000, Secondary, Goat polyclonal to mouse IgG at 1/50000 dilution, Predicted band size: 76, 88 KDa, Observed band size: 76, 88 KDa, Exposure time：5min
